Efficient Design
Modulating Components: Inverter Compressors, EC Condenser Fans, Direct-Drive Supply Fans
Optional Air Source Heat Pump with 0°F Lockout
ELEVATED CAPABILITIES & PERFORMANCE
ROOFTOP UNITS
ROOFTOP UNITS DESIGNED FOR TODAY'S BUILDINGS
Valent rooftop units (RTUs) solve today’s design challenges of increased efficiency and indoor air quality demands through a revolutionary approach to temperature and humidity control. With many value-added features included as standard like inverter scroll compressors and direct-drive fans, Valent RTUs are designed to operate efficiently while delivering comfortable ventilation air.
These units are ideal for mixed-air applications and are capable of higher percentages of outdoor air than traditional packaged rooftops. For high outdoor air products, apply Valent DOAS products.
OVERVIEW: ROOFTOP UNITS
Airflow Capacity
- 500-13,000 CFM
- Mixed air applications
Cooling Capacity
- 3-30 tons
Heating Options
- Indirect gas 50-600 MBh
- Up to 10:1 furnace turndown
- Modulating gas furnace
- Electric 10-140kW
- Air source heat pump
Cooling Options
- Air source heat pump
- Inverter scroll compressors
- Modulating hot gas reheat
- Modulating EC condensing fans
- Packaged DX
- Microchannel coil technology
Control Options
- Full controls
- Heat-cool only control
Construction
- Double wall cabinet
- Injected foam insulation, including the base
- 2,500-hour rated pre-painted exterior
- Multiple access doors with rugged handles
