ELEVATED CAPABILITIES & PERFORMANCE

ROOFTOP UNITS

Home r-arrow Products r-arrow

ROOFTOP UNITS DESIGNED FOR TODAY'S BUILDINGS

Valent rooftop units (RTUs) solve today’s design challenges of increased efficiency and indoor air quality demands through a revolutionary approach to temperature and humidity control. With many value-added features included as standard like inverter scroll compressors and direct-drive fans, Valent RTUs are designed to operate efficiently while delivering comfortable ventilation air.

These units are ideal for mixed-air applications and are capable of higher percentages of outdoor air than traditional packaged rooftops. For high outdoor air products, apply Valent DOAS products.

      OVERVIEW: ROOFTOP UNITS

      Airflow Capacity

      • 500-13,000 CFM
      • Mixed air applications

      Cooling Capacity

      • 3-30 tons

      Heating Options

      • Indirect gas 50-600 MBh
      • Up to 10:1 furnace turndown
      • Modulating gas furnace
      • Electric 10-140kW
      • Air source heat pump

      Cooling Options

      • Air source heat pump
      • Inverter scroll compressors
      • Modulating hot gas reheat
      • Modulating EC condensing fans
      • Packaged DX
      • Microchannel coil technology

      Control Options

      • Full controls
      • Heat-cool only control

      Construction

      • Double wall cabinet
      • Injected foam insulation, including the base
      • 2,500-hour rated pre-painted exterior
      • Multiple access doors with rugged handles
